RADIFOCUS™ Angiographic Catheter (image)
Angiographic Catheters

RADIFOCUS™ Angiographic Catheter

Angiographic Catheter
  • Smooth navigation thanks to the polyamide surface, rounded tip and one-piece body structure.
  • Soft and atraumatic catheter with good torque control due to its internal metallic mesh braid.
  • Smooth, radiopaque surface to prevent thrombus formation.
  • High pressure resistance (up to 1,000 psi/6.895 kPa)
  • Various tip shapes available.
Please contact your local representative for product details and catalogs.
A 5Fr angiographic catheter intended for use in angiographic procedures
  • Smooth navigation thanks to the polyamide surface, rounded tip and one-piece body structure.
  • Soft and atraumatic catheter with good torque control due to its internal metallic mesh braid.
  • Smooth, radiopaque surface to prevent thrombus formation.
  • High pressure resistance (up to 1,000 psi/6.895 kPa)
  • Various tip shapes available.
Specification table of RADIFOCUS™ Angiographic Catheter (image)
Country Select
Formulation No./ Model No. Shape Image Category Tip shape/Tip figure Outer diameter(Fr.) Outer diameter (mm) Inner diameter(mm) Usable catheter length (cm) Side holes
RF*DF25008M
Endovascular Mikaelsson 5 1.70 1.10 80 0
RF*DG3500GM
Endovascular RH 5 1.70 1.10 65 0
RF*DG36008M
Endovascular RH 6 2.00 1.10 80 0
RF*DGD5008WM
Endovascular RH 5 1.70 1.10 80 0
RF*DGI5007WM
Endovascular YASHIRO 5 1.70 1.10 70 0
RF*EB25010M
Endovascular Headhunter 3 5 1.70 1.10 100 0
RF*EB45010M Endovascular Hilal modified headhunter 5 1.70 1.10 100 0
RF*EC25010M
Endovascular Newton technique 2 5 1.70 1.10 100 0
RF*EH35010M
Endovascular Vertebral 5 1.70 1.10 100 0
RF*FK15008M Endovascular Straight 5 1.70 1.10 80 0
